Model
|
HV51.2V200Ah
|
|||||
|
Battery type
|
LiFePO4
|
|||||
|
Module Energy
|
10.2kwh
|
|||||
|
Module Nominal Voltage
|
51.2V
|
|||||
|
Module Capacity
|
200Ah
|
|||||
|
Module Dimension
|
383*605*240(W/D/H,mm)
|
|||||
|
Module Weight
|
77kg (Approximate)
|
|||||
|
Battery Module Qty InSeries(Optional)
|
6
|
7
|
8
|
9
|
10
|
11
|
|
System Nominal Voltage
|
307.2V
|
358.4V
|
409.6
|
460.8V
|
512V
|
563.2V
|
|
System Operating Voltage(v)
|
278.4-345.6
|
324.8-403.2
|
371.2-460.8
|
417.6-518.4
|
464-576
|
510.4-633.6
|
|
System Energy
|
61.44kwh
|
71.68kwh
|
81.92kwh
|
92.16kwh
|
102.4kwh
|
112.64kwh
|
|
System Usable Energy(kwh)(90%DOD)
|
55.3
|
61.51
|
73.73
|
82.94
|
92.16
|
101.38
|
|
Charge/Discharge Current
|
Recommend:50A Max:100A
|
|||||
|
Working Temperature
|
-20~60 (°C)
|
|||||
|
Cooling Mode
|
Air Conditioner
|
|||||
|
Communication Port
|
CAN/RS485
|
|||||
|
Humidity
|
5%~85%RH
|
|||||
|
Altitude
|
＜2000m
|
|||||
|
IP Rating of Enclosure
|
IP65
|
|||||
|
Dimension(w/D/H,mm)
|
1394*1015**2164.5
|
|||||
|
Weight Approximate
|
868kg
|
946kg
|
1024kg
|
1102kg
|
1180kg
|
1258kg
|
|
Installation
|
Integrated cabinet installation
|
|||||
|
Storage Temperature
|
0~35(°C)
|
|||||
|
Cycle Life
|
≥6000 times
|
|||||
|
Warranty
|
10 years (5+5)
|
|||||
|
Certification
|
UN38.3,MSDS,CE,ROHS,IEC62619
|
|||||
|
The current is affected by temperature and SOC
|
||||||
